Scrap Shear

Product Features:

1. It adopts HARDOX400 sheet material, with high strength, light dead weight and large shear force.

2.The included angle design can more easily hook the material, the sharp knife straightly cuts off the structural steel.

3 Applicable to dismantling of steel structure facilities such as heavy-duty vehicle dismantling, steel ship dismantling and bridge dismantling.

For more information, please e-mail or call us.

Online message
Warning: Invalid argument supplied for foreach() in /www/wwwroot/www.juxiangmachinery.com/wp-content/themes/juxiang/single-product.php on line 268
Message Board
Model Unit JX08 JX10
Weight kg 2086 3397
Max Opening mm 480 610
End Shear Force T 1000 1630
Middle Shear Force T 1780 2790
Max Shear Force T 4170 5965
Blade Length mm 480/550 620/690
Drive Oil Pressure kg/cm² 320 380
Suitable Excavator t 20-28 30-42
